Skyjack SJ40/45 T+ | 40-45 ft. | 94 in Deck | Rough Terrain Dual Fuel Scissor Lift

General

• Make: Skyjack
• Model: SJ40 T+ / SJ45 T+
• Type: Telescopic boom lift, 4WD
• Power: Diesel
• Machine weight: 14,805 lb (6,715 kg) / 15,780 lb (7,160 kg)

Working range

• Platform height: 40 ft 7 in (12.37 m) / 45 ft 1.5 in (13.75 m)
• Working height: 46 ft 7 in (14.20 m) / 51 ft 1.5 in (15.58 m)
• Horizontal reach: 33 ft 11 in (10.34 m) / 39 ft 8.25 in (12.10 m)
• Tailswing: 3 ft 8 in (1.12 m)

Platform

• Platform capacity (unrestricted / restricted): 750 / 1,000 lb (340 / 454 kg) on SJ40 T+; 660 / 1,000 lb (300 / 454 kg) on SJ45 T+
• Platform size: 36 x 96 in (0.91 x 2.44 m); optional 36 x 72 in (0.91 x 1.83 m)
• Platform rotation: 170°

Drive and controls

• Drive: AXLDRIVE four-wheel drive
• Controls: EASYDRIVE (drive and steer always oriented to the operator)
• Wiring: SKYCODED color-coded and numbered system

Dimensions

• Stowed width: 7 ft 6 in (2.29 m)
• Stowed height: 7 ft 10.5 in (2.40 m)
• Transport height (SJ45 T+): 9 ft 7 in (2.92 m)
